Synology E10G18-T1
Network adapter | PCIe 3.0 x4 low profile | 10Gb Ethernet x 1 | for Disk Station DS1618; RackStation RS1219, RS2418, RS2818, RS3618, RS818
More like this
In this category:
Main Specification
| Product Description | Synology E10G18-T1 - network adapter - PCIe 3.0 x4 - 10Gb Ethernet x 1 |
|---|---|
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x4 |
| Ports | 10Gb Ethernet x 1 |
| Dimensions (WxDxH) | 1.36 cm x 8.6 cm x 6.81 cm |
| Cabling Type | Ethernet 10GBase-T, NBase-T |
| Data Link Protocol | 10GbE |
| Data Transfer Rate | 10 Gbps |
| Compliant Standards | IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3an, IEEE 802.3bz |
| Manufacturer Warranty | 5-year warranty |
| Designed For | Disk Station DS1517, DS1618, DS1817, DS3018, DS3611, DS3612, DS3615, DS3617; FlashStation FS1018, FS2017, FS3017; RackStation RC18015, RS10613, RS1219, RS18016, RS18017, RS2418, RS2818, RS3411, RS3412, RS3413, RS3614, RS3617, RS3618, RS4017, RS818 |
General
| Device Type | Network adapter |
|---|---|
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x4 |
Networking
| Ports | 10Gb Ethernet x 1 |
|---|---|
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10GBase-T, NBase-T |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Features | Flow control, auto-negotiation, full duplex mode, TCP/IP checksum offload, UDP/IP checksum offload, 9 KB Jumbo Frame |
| Compliant Standards | IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3an, IEEE 802.3bz |
Expansion / Connectivity
| Interfaces | 1 x 10GBase-T - RJ-45 |
|---|
Miscellaneous
| Included Accessories | Low-profile bracket, full-height bracket |
|---|
Dimensions & Weight
| Width | 1.36 cm |
|---|---|
| Depth | 8.6 cm |
| Height | 6.81 cm |
Manufacturer Warranty
| Service & Support | Limited warranty - 5 years |
|---|
Environmental Parameters
| Min Operating Temperature | 0 °C |
|---|---|
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% |
Compatibility Information
| Designed For | Synology Disk Station DS1517+, DS1618+, DS1817+, DS3018xs, DS3611xs, DS3612xs, DS3615xs, DS3617xs Synology FlashStation FS1018, FS2017, FS3017 Synology RackStation RC18015XS+, RS10613xs+, RS1219+, RS18016xs+, RS18017XS+, RS2418+, RS2418RP+, RS2818RP+, RS3411RPXS, RS3411XS, RS3412RPxs, RS3412xs, RS3413xs+, RS3614RPxs, RS3614XS, RS3614XS+, RS3617RPxs, RS3617xs, RS3617xs+, RS3618XS, RS4017XS+, RS818+, RS818RP+ |
|---|
Product features
Enhanced connectivity
The Synology E10G18-T1 network adapter offers a high-speed 10GBase-T RJ-45 connector, ensuring rapid data transfer rates of up to 10 Gbps. This feature allows for efficient handling of data-intensive tasks, making it an ideal solution for environments requiring high bandwidth.Robust performance
Equipped with features like 9 KB Jumbo Frame, TCP/IP and UDP/IP checksum offload, the E10G18-T1 ensures smooth and reliable data transmission. Its support for auto-negotiation and flow control, along with full duplex mode, enhances network efficiency and performance.Wide compatibility
This network adapter supports a range of standards including IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, and IEEE 802.3x, making it versatile for various networking environments. Its compatibility with Ethernet 10GBase-T and NBase-T cabling types further extends its utility.Key selling points
- 10 Gbps data transfer rate for high-speed networking
- Supports Ethernet 10GBase-T and NBase-T cabling types for versatile use
- Features like auto-negotiation and flow control for enhanced network efficiency
- Low-profile form factor for easy integration into various systems
References
MPN: E10G18-T1
